- Size: 1.5 m X 3.0 m
- Place of Origin: China
- Brand Name: VICCAM
- Model Number: VL1530J050
- Weight: 10000.000 kg
Technology parameters
| Model | VL1530J050 |
| Working range(XY): | X axis 1500mm Y axis 3000mm |
| Max. axis speed simultaneous | 100m/min |
| Power of Laser Resource | 500W |
| Power Supply | 220V±10%，50/60Hz |
| Total electrical consumption of system | 13KW |
| Max.material thickness with 500w Fiber Laser Sauce: | Mild steel: 5mm Stainless steel: 2mm |
| Dimensions: | Length 5400mm Width 2500mm Height 1200mm |
Product description
Feature:
The VL1530J050 fiber is an entry-level solution with key advantages. In addition to cutting standard materials such as mild and stainless steel materials are processed reliably and cost effectively.
Benefit
Enhanced productivity in thin sheets
Affordable entry into laser-cutting
Low investment and operating costs
Extremely simple to operate
Efficiency
Simple design and short installation time
Easy to operate and lower training costs
Minimal downtime due to maintenance-free fiber beam guide
Machine detail
Compact machine size save your workshop space.
Highly precise transmission parts ensure your processing more accuracy.
Friendly control program interface help you easy operating the machine for processing.
